90° Corner Bracket · TSAF-129
TSAF-129
90° Corner Bracket – TSAF-129
SS-316 bracket that turns the horizontal lifeline through 90° at corners.
Used in
Specifications
| SKU | TSAF-129 |
|---|---|
| Material | SS-316 |
| Finishing | Natural Finish |
| Weight | 0.82 kg |
| Fixing | Through SS-304 Fasteners |
The TSAF 129 90° Corner Bracket changes the direction of the Horizontal Lifeline System through a right angle. The catalogue notes that the corner bend is mostly used at roof corners, or wherever the site layout requires the line to turn.
The bracket is made from SS-316 with a natural finish, weighs 0.82 kg and is fixed through SS-304 fasteners. Its curved profile allows the lifeline to follow building contours so that workers can continue along the line around corners. Corner positions are set during system design.
Downloads
- Datasheet available on request — add this product to your enquiry.
Specifications are indicative. Refer to the product datasheet or ask our engineers for project-specific values.
