Roof Post for End, Corners & Intermediate · TSAF-112A
TSAF-112A
Roof Post for End, Corners & Intermediate – TSAF-112A
Anodised AL 6063 T6 roof post, 680 x 540 x 46 mm, suitable for end, corner and intermediate positions and fixed by aluminium riveting.
Used in
Specifications
| SKU | TSAF-112A |
|---|---|
| Size (LxBxH) | 680 x 540 x 46mm |
| Roof Post Plate Material | AL 6063 T6 |
| Roof Post Clamps Material | AL 6063 T6 |
| Finishing | Anodizing Natural Finish |
| Fixing | Through Aluminium Riveting |
The TSAF 112A Roof Post is an aluminium base that can be used at end, corner and intermediate positions of the Horizontal Lifeline System. It measures 680 x 540 x 46 mm (L x B x H). Both the roof post plate and the roof post clamps are made from AL 6063 T6 with an anodised natural finish.
Unlike the posts fixed through SS-304 fasteners, the TSAF 112A is fixed through aluminium riveting. Using one post type for all positions can simplify the layout on a roof where the same profile runs throughout. Suitability for the roof sheet is confirmed during system design.
Downloads
- Datasheet available on request — add this product to your enquiry.
Specifications are indicative. Refer to the product datasheet or ask our engineers for project-specific values.
