TsaF BallastSafe Energy Absorbing · BS-EA-PAP-350
BS-EA-PAP-350
TsaF BallastSafe Energy Absorbing – BS-EA-PAP-350
MS ballast-weighted anchor of 350 kg overall, built from 12 identical, interchangeable 23 kg blocks, with a 5-year maintenance cycle.
Used in
Specifications
| SKU | BS-EA-PAP-350 |
|---|---|
| Material | MS |
| Overall Device Weight | 350 kg |
| Weight per Block | 23 kg |
| Number of Blocks | 12 pieces (identical & interchangeable) |
| Maintenance Cycle | 5 Years |
| Colour | Grey |
TsaF BallastSafe Energy Absorbing (BS-EA-PAP-350) is a ballast-weighted anchor in the Mobile Anchor Series, part of the Anchorline & Rescue System. It provides an anchor point on surfaces where drilling or fixing into the structure is not wanted, such as flat roofs.
It is made from MS and finished in grey. The overall device weight is 350 kg. The ballast is made up of 12 identical and interchangeable blocks of 23 kg each, so the unit can be handled in parts and assembled on site. The catalogue gives a maintenance cycle of 5 years.
Downloads
- Datasheet available on request — add this product to your enquiry.
Specifications are indicative. Refer to the product datasheet or ask our engineers for project-specific values.
